Circuit Board Charging Station all models G3 P2 -NSG3-
(Item number: AM-592894503)
Latest circuit board for the charging station of all G3 - P2 Automower® models.
Charging station board G3-P2
PCB P2 CS Board Type 42-44
582 89 45-01 = Alte Version / Old Version
582 89 45-02 = Alte Version / Old Version
582 89 45-03 = Alte Version / Old Version
582 89 45 04 = Version 4 = Aktuell Version / New Version / 2024
Note:
Circuit board was changed several times. It has also been optically changed.
The circuit board is suitable for all P2 models, see list below.
After installing the new board.
Readjust the loop signal.
1. The LED on the charging station must light up green.
(If flashes, there is an error on the charging station or on the loops)
2. Place Automower® in the charging station
3. Automower® "Menu" => Security (lock symbol)
4. Check "New loop signal" okey
5. Wait, successful or changed must appear.
SUITABLE COMPATIBLE
The item is suitable and compatible for following models and types*
| Marke | Modell | Generation | Plattform | Modelljahr |
|---|---|---|---|---|
| Husqvarna | Automower® 320 | G3 | P2 | (2013, 2014, 2015) |
| Husqvarna | Automower® 330X | G3 | P2 | (2013, 2014, 2015) |
| Husqvarna | Automower® 420 | G3 | P2 | (2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023) |
| Husqvarna | Automower® 430X | G3 | P2 | (2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023) |
| Husqvarna | Automower® 430XH (USA) | G3 | P2H | (2019, 2020, 2021, 2022) |
| Husqvarna | Automower® 435X AWD | G4 | P25 | (2019, 2020, 2021, 2022, 2023, 2024) |
| Husqvarna | Automower® 440 | G3 | P2 | (2017, 2018, 2019, 2020, 2021, 2022) |
| Husqvarna | Automower® 450X | G3 | P2 | (2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023) |
| Husqvarna | Automower® 450XH (USA) | G3 | P2H | (2019, 2020, 2021, 2022) |
| Husqvarna | Automower® 520 | G3 | P2C | (2018, 2019, 2020, 2021, 2022, 2023) |
| Husqvarna | Automower® 535 AWD | G4 | P25 | (2019, 2020, 2021, 2022, 2023, 2024) |
| Husqvarna | Automower® 550 | G3 | P2C | (2018, 2019, 2020, 2021, 2022, 2023) |
| Husqvarna | Automower® 550H USA | G3 | P2C | (2019, 2020, 2022) |
*The maintain of our products will happen with care and good conscience. However, we do not take responsibility for any mistakes. If you are not sure about an item matching your model and type, feel free to contact us.
SPARE PART HISTORY / replacement part history
This spare part is up-to-date, but has a history of the spare part number.
The following spare part numbers are the same or compatible. Replaced parts*
* We do not take responsibility for accuracy of several informations.
