Main page » Spare parts » Baseplate with circuit board conversion kit repair kit G2 2004-2015 -NSG2-
Baseplate with circuit board conversion kit repair kit G2 2004-2015 -NSG2-
(Item number: AM-575708209)
Conversion kit for the base plate charging station 2004 to 2009 (2010)
For all Automower® G2 2004-2009 (2010)
Latest version of the charging station base plate.
An improved charging station was introduced from the mid / end of 2010 model and from 2011/2012.
This was equipped with a new, stronger base plate (pictures) and a stronger LED for the loop signal.
The old nails for attaching the base plate to the subsurface are being replaced by better plastic nail screws.
The old base plate is no longer available !!
Devices / charging stations with an old base plate have to be converted if they are defective.
With our kit you can convert all Automower® G2s yourself.
The kit is suitable for all Automower® models G2, 220AC, 230ACX, 260ACX from year of construction 2004 to 2009/2010
(From models (mid-end of 2010), 2011, 2012 the new base plate is already installed)
Content:
- Newest baseplate 2011 (AM-5752316XX)
- Latest matching charging station board (AM-5787884XX)
- Adapter cable for new board (if required) (AM-54478XXX)
- Set of matching screw nails 6 pieces (AM-575238601)
- Short conversion instructions in German
- Short conversion instructions in France
- Instructions for programming the board to your pin code (loop signal) (DEU, FR)
Modification:
- Expenditure: approx. 15-35 minutes
- Tool: Torx screwdriver (T20)
- NO software update required.
- No extra programming necessary.
- Conversion can be carried out by the owner himself.
After the conversion, a new "code transmission" must be carried out.
This is easy and can be done by the owner.
(Instructions in German and France are included with the delivery.)
Important:
Please select the year of construction correctly below!
Only then can we guarantee you a suitable installation kit !!
The type plate with the year of manufacture can be found on your Automower®, not on the charging station.
(Usually under the mower cover as a nameplate sticker)
Should no year of construction be recognizable?
Simply email with S / N and Prod. (Type plate) to us by email.
We will then tell you which set is the right one.
Shouldn't you find a nameplate?
Simply email with a description of what you pointed out. We help you.
Herstellerangaben gem. Produktsicherheitsverordnung:
Husqvarna Deutschland GmbHHans-Lorenser-Straße 40
89079 Ulm
Tel. 0731 490-2500
kundenservice@husqvarna.de
SUITABLE COMPATIBLE
The item is suitable and compatible for following models and types*
| Marke | Modell | Generation | Plattform | Modelljahr |
|---|---|---|---|---|
| Husqvarna | Automower® 220AC | G2 | 1 | (2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015) |
| Husqvarna | Automower® 230ACX | G2 | 1 | (2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014) |
| Husqvarna | Automower® 260ACX | G2 | 2 | (2009, 2010, 2011) |
| Husqvarna | Automower® 265ACX | G2 | 2 | (2012, 2013, 2014, 2015) |
| Husqvarna | Automower® G2 | G2 | 1 | (2004, 2005, 2006) |
| Husqvarna | Automower® Solar Hybrid | G2 | 1 | (2008, 2009, 2010, 2011, 2012) |
| Husqvarna | Automower® Solar Hybrid (Black Metalic Edition) | G2 | 1 | (2013, 2014, 2015) |
| Gardena® | Gardena® R160 (G2) | G2 | 1 | (2013, 2014, 2015) |
*The maintain of our products will happen with care and good conscience. However, we do not take responsibility for any mistakes. If you are not sure about an item matching your model and type, feel free to contact us.
SPARE PART HISTORY / replacement part history
This spare part is up-to-date, but has a history of the spare part number.
The following spare part numbers are the same or compatible. Replaced parts*
* We do not take responsibility for accuracy of several informations.
